- Disc Springs: How To Calculate The Spring Stress
Disc
Springs
When The Spring Is Subjected to a Static Load or Low-Level Repeated Load
When used under a static load or subjected to less than 5000 cycles within the usage period, it is recommended that the absolute value of maximum compressive stress (σI) at a deflection of 0.75 h0 does not exceed 2,500 N.
When The Spring Is Subjected to a Repeated Load
In the case of the spring subjected to a repeated load, calculate the respective tensile stresses of σII and σIII at the maximum and minimum loads. As a result of the calculation, examine the maximum and minimum values of σII and σIII.
Note that repeatability when SUP10(Correspond to 51CrV4,6150) spring steel is used is shown in Figures 3 to 5. If the material used is SK5M, it is safer to consider the value as 80% of the figure.
